JL-246CR photocontrol can apply to independent control application or system control application, such as roads, exhibitions, schools, shopping malls, supermarkets, factories, parks and so on.
This product consists a ZigBee communication module as well as a RS485 communication module to allow its ZigBee group remoted with a smart IoT management system.
Product size
Product Features
ANSI C136.41 Twist-lock
0~10V Dimming
Surge protection level: 6KV/3KA differential mode
Sandwich cover for Long Life
Multi-Volts Application
IP67 Ready
IR-fiRS485red Phototransistor
Model No. | JL-246CR |
Rated Voltage | 120~277VAC |
Applicable Voltage Range | 105~305VAC |
Rated Frequency | 50/60Hz |
Dimming Output | 0~10VDC |
Wireless Communication（up） | RS485 |
Wireless Communicatio（down） | Zigbee |
Spectral Acquisition Range | 350~1100nm；Peak wavelength 590nm |
Rated Loading | 1000W Tungsten ; 1000VA Ballast ; 8A@120V 5A@208-277 e-Ballast |
Operate Levels | Turn-On＜100Lx，Turn-Off＞150Lx / per client request |
Power Consumption | 1.2W static，3.4W dynamic |
Operating Temperature | -40℃~70℃ |
Operating Humidity | 96% |
Failure mode | Fail-On |
Shell material | PC+PC |
High protection | Double Shell |
Surge protection level | 6KV/3KA differential mode |
IP level | IP65/IP67 |
Factory Settings | Remote control+Adaptive mode |
FCC | ● |
Certifications |
|
Criterion | IEC61000-4-5;IEC61000-4-2;IEC61000-4-3; IEC61000-4-6;GB/T 17743-2017;IEC61000-4-4; IEC61000-4-11;IEC61000-3-2;GB/T2423.10-2008; UL94-V0; |
