JL-722A3 light controller products are intelligent rotary lock light controllers developed based on ZHAGA BOOK18 interface standard.It adopts light sensing and microwave mobile combined sensor, which can output DALI2.0 dimming signal.
The light controller is suitable for lighting scenes such as roads,lawns, courtyards, parks, car park and construction site.
Product size
Product Features
light sense + microwave, lighting on demand, more humanized and power saving
microwave anti false triggering, indoor and outdoor
automatic dynamic microwave frequency adjustment to avoid mutual interference in dense installation
comply with zhaga book18 interface standard
DC power supply, ultra low power consumption
support DALI2.0 dimming mode
compact size, suitable for installation to various lamps
anti false triggering design of interference light source
reflected light compensation design of lamps
waterproof protection grade up to IP66
Model | JL-722A3 |
Power Supply | Rated voltage：12~24VDC Rated current：12V/45mA；24V/30mA |
Power Consumption | 12V/3.5mA；24V/3.5mA |
Dimming | DALI2.0 |
Spectral Acquisition Range | 350~1100nm，Peak wavelength 550nm |
Turn on Illuminance | 50Lux（±10） |
Turn off Illuminance | Reflected light + 40Lux（±10）after each turn on Lower limit：50+40Lux（±10） ； Upper limit：6000Lux（±100） |
Reflected light compensation upper limit | 6000Lux（±100） |
Initialization | After power on, the light is turned on by default and maintains 5S, then automatically turns off the light and enters the auto-sensing operation mode *1 |
Turn on delay | 5S |
Turn off delay | 60S |
0%~20%；20%~100% Brightness change time | 1S |
100%~20%；X%~0% Brightness change time | 8S |
100% brightness hold time after microwave trigger | 30s |
Stand-by Dimming | 20% |
Maximum hanging height of microwave | 15M |
Sensing radius | 4-8M (by 15m hanging height) |
Microwave induction angle | 92° |
Microwave anti-false trigger | Can prevent wind, rain, leaves, and small animals |
Mechanical Vibration | IEC60068-2-6 |
Flammability Level | UL94-V0 |
Operating Temperature | -40℃~70℃ |
Storage Temperature | -40℃~85℃ |
Operating Humidity | 5%RH~99%RH |
IP Level | IP66 |
Certifications |  |
